Hikvision DS-KAS-7M01(O-STD) Accessory Kit for Access Control Terminal

Hikvision DS-KAS-7M01(O-STD) Accessory Kit is a complete access control installation package designed to complement Hikvision face recognition terminals and access controllers. This all-in-one kit includes essential components such as a magnetic lock, power supply, exit button, and mounting brackets, enabling quick and reliable deployment of a secure door access system. Engineered for durability and compatibility, it simplifies installation while ensuring strong door holding force and stable power management for professional security applications.

Product Features

Complete Access Control Kit

Includes all key components required for a standard door access setup, reducing the need for separate purchases and ensuring system compatibility.

High-Performance Magnetic Lock

Equipped with a magnetic lock offering up to 272 kg holding force, providing strong and reliable door security for various door types.

Stable Power Supply Unit

Features a regulated power supply with 12 V DC output and support for backup battery charging and discharging, ensuring uninterrupted operation.

Durable Exit Button with LED Indicator

Comes with a stainless steel exit button featuring an LED indicator for clear operation status and long-lasting performance.

Flexible Installation with Mounting Brackets

Includes L and Z brackets for easy installation on wooden, glass, and metal doors, offering versatile mounting options.

Wide Compatibility with Access Terminals

Designed to integrate seamlessly with Hikvision access control terminals, making it suitable for offices, commercial buildings, and residential systems.

Reliable and Durable Construction

Built with high-quality materials such as aluminum alloy and electroplated components to ensure long-term durability and resistance to wear.

Product Specifications

• Model: DS-KAS-7M01(O-STD)
• Kit Components: Power supply, magnetic lock, exit button, lock brackets (L and Z)
• Power Input: 110 to 230 VAC
• Power Output: 12 V DC, 24 W
• Momentary Current: 5 A
• Persistent Current: Up to 5 A
• Backup Support: Battery charging and discharging supported
• Magnetic Lock Holding Force: Up to 272 kg (600 lbs)
• Lock Dimensions: 250 mm × 28 mm × 48 mm
• Armature Plate Dimensions: 180 mm × 38 mm × 12 mm
• Bracket Type: L and Z brackets
• L Bracket Dimensions: 250 mm × 46 mm × 30 mm
• Z Bracket Dimensions: 180 mm × 47 mm × 47 mm
• Exit Button Material: Stainless steel panel
• Exit Button Voltage: 12 to 24 V DC
• Operating Temperature (Power Supply): -10°C to 50°C
• Operating Temperature (Lock): -10°C to 55°C
• Operating Temperature (Exit Button): -20°C to 55°C
• Compatible Door Types: Wooden, glass, and metal doors
• Application: Access control system installations for indoor and semi-outdoor use
