APC Easy UPS SMV 1000VA Universal Outlet 230V (SMV1000I-MS)

APC Easy UPS SMV 1000VA (SMV1000I-MS) is a compact and efficient Power Back-up UPS designed for small offices, home businesses, and essential electronics. This Uninterruptible Power Supply in Kenya offers dependable protection against surges, brownouts, and blackouts, ensuring that your devices remain safe and operational during unstable power conditions. Featuring AVR, universal outlets, and user-replaceable batteries, it is a practical choice for users seeking reliability without complexity.

Product Features

Essential Backup Power for Home and Office
Provides 1000VA / 600W of backup power, ideal for Wi-Fi routers, workstations, printers, and surveillance systems.

Automatic Voltage Regulation (AVR)
Boost and Trim AVR stabilizes input voltage without switching to battery power, extending battery life.

Universal Outlet Design
Equipped with three universal output sockets, compatible with multiple plug types for flexible connectivity.

Stepped Sinewave Output
Delivers simulated sinewave power suitable for common electronic devices and office equipment.

Extended Runtime at Low Load
Delivers up to 40 minutes of runtime at 50W load, ensuring essential systems can be safely shut down or maintained.

Hot-swappable, User-replaceable Battery
Minimizes downtime with easy battery replacement when needed.

LED Status Indicators & Audible Alarms
Visual and audible alerts keep you informed of UPS status—battery mode, overload, and low battery.

Surge and Noise Protection
Built-in 156 Joule surge protection and EMI/RFI filtering safeguard connected equipment from power disturbances.

Product Specifications

• Model: SMV1000I-MS
• Brand: APC by Schneider Electric
• Capacity: 1000VA / 600W
• Form Factor: Tower

Input

• Input Voltage: 230V
• Input Frequency: 45–65 Hz (auto-sensing)
• Input Connection: Universal plug

Output

• Output Voltage: 230V (nominal)
• Output Regulation (Battery Mode): ±10%
• Output Frequency (Battery Mode): 50/60 Hz ± 1 Hz
• Waveform Type: Stepped approximation to a sinewave
• Output Connections: 3 x universal outlets

Battery

• Battery Type: Sealed lead-acid, maintenance-free
• Recharge Time: 6–8 hours to 90% capacity
• Battery Runtime:
  • 50W load: Up to 40 minutes
  • 200W load: Up to 10 minutes
  • 600W (full load): Up to 3 minutes
• Battery Replacement: Hot-swappable, user-replaceable

Protection & Monitoring

• Surge Energy Rating: 156 Joules
• AVR: Boost and Trim AVR
• Noise Filter: EMI/RFI filtering
• LED Indicators: Online, On Battery, Replace Battery, Overload
• Audible Alarms: Backup mode, low battery, overload

Physical

• Dimensions (HxWxD): 138 x 99 x 310 mm
• Weight: 6.6 kg

Environment

• Operating Temperature: 0–40°C
• Humidity: 0–95% (non-condensing)
• Altitude: Up to 3,000 meters

Certifications

• Safety Standards: IEC 62040-1, IEC 60950-1
• Environmental: RoHS, REACH
• Warranty: 2-year repair or replace (with Kenya-based support)

Applications

• Home Office Equipment: Keeps computers, modems, and routers running during outages.
• Retail POS Systems: Prevents data loss in billing and payment systems.
• CCTV and Surveillance: Maintains power to DVRs and IP cameras for uninterrupted security.
• SMBs and SOHO Setups: Provides backup for printers, NAS drives, and switches.
