UGREEN CM101 HDMI To VGA+HDMI+3.5mm Converter – 40744

UGREEN CM101 HDMI to VGA + HDMI + 3.5 mm Converter (Model 40744) is a versatile active video adapter that lets you split or convert a single HDMI source into multiple outputs — delivering HDMI passthrough, VGA analog video, and a 3.5 mm audio output simultaneously. Designed for presentations, hybrid workstations, classrooms, and multimedia setups, this converter allows you to connect HDMI devices to legacy VGA displays while still keeping a digital HDMI feed and separate audio output — ideal for extending screens, mirroring displays, and routing sound to external speakers or soundbars.

Product Features

HDMI Input to Multiple Outputs

Converts one HDMI source to three useful outputs:

• HDMI out — passthrough to a second digital display
• VGA out — analog video for older monitors/projectors
• 3.5 mm audio — analog audio output for external speakers/headsets

Dual Display Support

Supports feeding two different displays simultaneously — one via HDMI and one via VGA — allowing flexible screen setups for work or presentations.

Full HD Video Support

Delivers high‑definition video output up to 1920 × 1080 @ 60 Hz on both HDMI and VGA outputs, ensuring crisp visuals for presentations, streaming, or desktop extensions.

Separate Audio Output

Includes a 3.5 mm analog audio port, enabling external speakers or headphones to receive audio from the HDMI source — ideal when the display does not support audio over VGA.

Active Signal Conversion

Built‑in active conversion chipset handles digital‑to‑analog translation cleanly and reliably, so you can connect modern HDMI devices to legacy screens without flickering or signal issues.

Plug‑and‑Play Operation

No drivers or software required — simply connect your HDMI source and displays, then plug in audio for instant video and sound output.

Compact and Durable Build

Constructed with quality connectors and compact housing that fits neatly into desktop, classroom, or conference setups without crowding cables.

Product Specifications

• Model: CM101 (40744)
• Input: HDMI Type‑A male (from source device)
• Outputs:
  • 1 × HDMI Type‑A female (digital video output)
  • 1 × VGA female (15‑pin D‑Sub) (analog video output)
  • 1 × 3.5 mm audio jack (analog audio output)
• Supported Resolution: Up to 1920 × 1080 @ 60 Hz
• Audio: Analog audio out via 3.5 mm jack
• Converter Type: Digital HDMI → Analog VGA + HDMI passthrough + audio separation
• Power: Typically USB‑powered or passive (verify included cable)
• Plug‑and‑Play: Yes (no driver required)
• Typical Uses: Dual display output, legacy projector support, external audio routing, HDMI extension/mirroring
