TP-Link AX3600 High Density Multi‑Gigabit Ceiling Mount Wi‑Fi 6 Access Point – TL‑EAP660 HD

TP-Link TL‑EAP660 HD is a powerful Wi‑Fi 6 access point designed for high-density, enterprise-level environments that demand reliable, ultra-fast connectivity. With AX3600 dual-band throughput (1148 Mbps on 2.4 GHz and 2402 Mbps on 5 GHz), this ceiling-mount access point ensures smooth performance for over 1,000 concurrent users. It seamlessly integrates with the Omada SDN platform for centralized cloud or local management, zero-touch provisioning, and advanced guest authentication. Ideal for office buildings, schools, and large indoor venues, the EAP660 HD delivers cutting-edge Wi-Fi 6 performance, PoE+ power, and robust enterprise security.

Product Features

ultra-fast wi‑fi 6 speeds
Delivers a combined AX3600 wireless performance with 1148 Mbps on 2.4 GHz and 2402 Mbps on 5 GHz, ensuring high throughput and reduced latency for demanding wireless applications.

high-density client capacity
Supports over 1,000 concurrent clients using OFDMA and MU‑MIMO technologies, providing four times the capacity of legacy Wi‑Fi 5 networks—ideal for offices, schools, or auditoriums.

mobile-first centralized management
Fully compatible with the Omada SDN system for cloud-based or on-premise control, including app management, remote monitoring, and zero-touch provisioning.

multi-gigabit uplink and poe+ support
Equipped with a 2.5 Gbps Ethernet port for high-speed backhaul and supports 802.3at PoE+ or 12V DC power, enabling flexible and clean installations with minimal cabling.

seamless roaming and network optimization
Supports 802.11k/v/r, band steering, load balancing, and beamforming for uninterrupted roaming and optimal client distribution across your wireless network.

secure guest network and robust security
Advanced captive portal features with SMS, Facebook Wi-Fi, and voucher login, plus enterprise-grade protections including WPA3, 802.1X, MAC filtering, and rogue AP detection.

Product Specifications

• Wireless standards: IEEE 802.11ax/ac/n/g/b/a
• Frequency bands: 2.4 GHz and 5 GHz
• Wireless speeds: up to 1148 Mbps (2.4 GHz), up to 2402 Mbps (5 GHz), total AX3600
• Concurrent client capacity: 1,000+ devices
• Ethernet port: 1× 2.5 Gbps RJ‑45 (PoE+ supported)
• Power options: 802.3at PoE+ or 12 V DC
• Power consumption: ~18.5 W (EU), ~21.5 W (US)
• Antennas: Internal omni-directional; 4×4 dBi @ 2.4 GHz, 4×5 dBi @ 5 GHz
• Mounting: Ceiling or wall mount (kits included)
• Dimensions: 243 × 243 × 64 mm
• Management tools: Omada app, cloud/hardware controllers (OC200/OC300), SNMP, SSH, HTTPS/HTTP
• Security features: Captive portal, MAC filtering, client isolation, SSID-to-VLAN, 802.1X, WPA2/WPA3 (Personal/Enterprise), rogue AP detection
• Wireless optimization: OFDMA, MU‑MIMO, beamforming, band steering, airtime fairness, rate limiting, scheduling
• Environmental: Operating temp 0–40 °C; humidity 10–90 % RH non‑condensing; storage −40–70 °C
• Certifications: CE, FCC, RoHS
• Package contents: EAP660 HD unit, power adapter, mounting kit, quick install guide
