Entrust Sigma DS3 Duplex ID Card Printer with Dual Laminator L2 (507920-004)

Entrust Sigma DS3 Duplex ID Card Printer with Commercial Dual Laminator L2 (Part No. 507920-004) is a high-performance ID card printing solution designed for secure, high-volume card issuance. Built for government institutions, financial organizations, universities, and corporate environments, this advanced system delivers vibrant dual-sided printing combined with professional-grade dual lamination for enhanced durability and security. With intuitive operation, secure cloud connectivity, and industry-leading print technology, the Sigma DS3 ensures reliable, high-resolution card production while protecting against fraud and tampering.

Product Features

High-Speed Duplex Printing

The Sigma DS3 offers automatic dual-sided printing, enabling fast and efficient production of employee badges, student IDs, access control cards, and financial cards. Its high-speed engine minimizes wait time while maintaining exceptional print clarity.

Commercial Dual Lamination Module (L2)

Equipped with the Sigma Commercial Lamination Module featuring a dual laminator (L2), this printer applies protective overlays or holographic laminates to both sides of the card. This enhances card lifespan, increases resistance to wear and tampering, and adds advanced visual security elements.

300 dpi Print Resolution with Vibrant Color Output

With 300 x 300 dpi dye-sublimation and resin thermal transfer technology, the printer produces sharp text, detailed images, barcodes, and crisp graphics suitable for secure identification applications.

Built-In Security Features

Designed with secure boot, encrypted data transfer, and Trusted Platform Module (TPM) architecture, the Sigma DS3 protects sensitive cardholder data. It also supports secure printing workflows through authentication and network protection features.

User-Friendly Interface and Remote Management

The printer features an intuitive LCD panel and supports remote printer management through web-based dashboards. Users can monitor printer status, manage print jobs, and receive alerts in real time.

Flexible Connectivity Options

Supports USB and Ethernet connectivity for seamless integration into secure network environments. Optional Wi-Fi connectivity is available for flexible deployment.

Scalable Encoding Options

The Sigma DS3 supports multiple encoding technologies including magnetic stripe, contact and contactless smart cards, and RFID encoding, making it suitable for advanced access control and payment systems.

Durable Industrial Design

Built with a robust frame and optimized internal components, the printer is designed for continuous commercial use in high-demand environments.

Product Specifications

• Model: Entrust Sigma DS3 Duplex with Commercial Dual Laminator L2
• Part Number: 507920-004
• Print Technology: Dye-sublimation and resin thermal transfer
• Print Resolution: 300 x 300 dpi
• Printing Capability: Single-sided and automatic duplex printing
• Lamination: Dual-sided lamination with L2 dual laminator module
• Print Speed: Up to approximately 225 full-color cards per hour (single-sided); speeds vary with lamination
• Card Capacity (Input Hopper): Up to 125 cards
• Card Capacity (Output Hopper): Up to 25 cards
• Card Types Supported: PVC, composite PVC, PET, and other ISO CR-80 cards
• Card Thickness Range: Approximately 0.25 mm to 1.02 mm (10–40 mil)
• Connectivity: USB 2.0, Ethernet; optional Wi-Fi
• Operating Systems Compatibility: Windows 10, Windows 11, Windows Server editions
• Security Features: Secure boot, TPM chip, encrypted data transfer
• Display: Integrated LCD control panel
• Dimensions: Compact desktop footprint suitable for office environments
• Power Supply: Auto-switching power supply
• Operating Environment: Office-grade indoor use

Entrust Sigma DS3 Duplex ID Card Printer with Dual Laminator L2 is an ideal solution for organizations that require secure, durable, and high-quality card issuance with advanced protection and professional finishing.
