Dell PowerEdge R760xs Rack Server Intel Xeon Silver 4514Y 64GB DDR5 10GbE OCP 16-Bay

Dell PowerEdge R760xs Rack Server is a high-performance enterprise 2U server engineered for virtualization, cloud workloads, and data-intensive business applications. Built on the Intel Xeon Silver 4514Y processor architecture and high-speed DDR5 memory, it delivers strong multi-core computing power, enhanced scalability, and efficient workload handling. With support for up to 16 hot-plug SAS/SATA drives, integrated 10GbE networking, and advanced remote management through iDRAC9 Enterprise, this server is designed for organizations that require performance, flexibility, and dependable infrastructure growth.

Product Features

Intel Xeon Silver 4514Y High-Performance Processor

The system is powered by the Intel Xeon Silver 4514Y processor featuring 16 cores and 32 threads, a base frequency of 2.0GHz, 30MB cache, and a 150W thermal design power. This processor is optimized for virtualization, enterprise applications, and multi-threaded workloads, delivering balanced performance and energy efficiency for modern data center environments.

High-Speed DDR5 ECC Server Memory

Equipped with 64GB DDR5 RDIMM memory running at 5600MT/s, the server provides high bandwidth and low latency performance for demanding workloads. The ECC single-rank memory architecture enhances system stability by detecting and correcting memory errors, ensuring reliable continuous operation.

High-Density 16-Bay Storage Architecture

The 2.5-inch chassis supports up to 16 SAS or SATA hot-plug drives, offering scalable storage capacity for growing business needs. This configuration allows flexible deployment for virtualization, database hosting, file storage, and high-performance enterprise applications.

Enterprise SSD for Fast System Responsiveness

The included 480GB SATA SSD hot-plug drive provides fast boot performance, improved application loading speeds, and reliable system responsiveness. It is designed for mixed-use workloads, ensuring stable performance for operating system and application environments.

Advanced RAID Protection with PERC H755 Controller

The integrated Dell PERC H755 SAS front RAID controller supports RAID 0, RAID 1, and RAID 5 configurations. It delivers enterprise-grade data protection, improved redundancy, and optimized storage performance for mission-critical workloads.

Dual Network Connectivity with 1GbE and 10GbE Support

The server includes Broadcom 5720 Dual Port 1Gb Ethernet for standard connectivity and management, along with a Broadcom 57416 Dual Port 10GbE BASE-T OCP NIC 3.0 adapter for high-speed data transfer. This combination ensures flexibility, scalability, and optimized network performance for enterprise environments.

iDRAC9 Enterprise Remote Management

Dell iDRAC9 Enterprise provides advanced remote server management, including monitoring, diagnostics, firmware updates, and system control. This reduces the need for physical intervention, improving uptime and operational efficiency.

Redundant Titanium Power Supply for Maximum Reliability

The system features dual redundant 1100W hot-plug Titanium power supplies supporting 100–240V AC input. This 1+1 redundancy ensures uninterrupted operation and protects against power supply failures in critical environments.

Expandable PCIe and OCP Architecture

With a 1×16 and 1×8 PCIe slot configuration and OCP NIC 3.0 support, the server provides flexibility for future upgrades such as additional networking cards, storage controllers, or accelerator modules.

Efficient 2U Rack-Optimized Design

The Dell PowerEdge R760xs features a durable 2U rack chassis with rack rails and standard bezel included. Its design ensures optimal airflow, serviceability, and density for modern data center deployments.

Product Specifications

• Product Model: Dell PowerEdge R760xs Rack Server
• Part Number: PER760XS1A – 02
• Server Form Factor: 2U Rack Server
• Processor: Intel Xeon Silver 4514Y
• Processor Cores: 16 Cores
• Processor Threads: 32 Threads
• Base Frequency: 2.0GHz
• Cache Memory: 30MB
• Thermal Design Power: 150W
• Memory Installed: 64GB DDR5 RDIMM
• Memory Speed: 5600MT/s
• Memory Type: ECC Single Rank RDIMM
• Maximum Drive Bays: Up to 16 x 2.5-inch SAS/SATA hot-plug drives
• Installed Storage: 1 x 480GB SATA SSD
• Drive Type: Hot-plug RI/AG Drive
• RAID Controller: Dell PERC H755 SAS Front
• RAID Levels Supported: RAID 0, RAID 1, RAID 5
• Networking: Broadcom 5720 Dual Port 1Gb On-Board LOM
• Additional Networking: Broadcom 57416 Dual Port 10GbE BASE-T OCP NIC 3.0
• Remote Management: iDRAC9 Enterprise 16G / 15G
• Expansion Slots: 1×16 + 1×8 PCIe (No Riser, OCP Support)
• Riser Configuration: No Riser (1 CPU configuration support)
• Power Supply: Dual Redundant 1100W Hot-Plug Titanium
• Power Input Range: 100–240V AC
• Chassis Type: 2U High-Density 2.5-inch Rack Chassis
• Included Accessories: Rack Rails, Standard Bezel
• Operating Environment: Data Center / Enterprise IT Infrastructure
• Warranty: 3-Year Basic Next Business Day Onsite Support
