Jinko 22kW Solar Pumping Inverter – Industrial MPPT Three Phase Solar Water Pump Controller

Jinko 22kW Solar Pumping Inverter is a high-capacity industrial solar pump controller engineered to power large three-phase AC water pumps directly from solar photovoltaic panels. Designed for large-scale irrigation projects, commercial farms, borehole water extraction, and community water supply systems, this inverter integrates advanced MPPT technology to maximize solar energy utilization and maintain stable pump performance throughout the day. With intelligent motor control, comprehensive protection systems, and durable construction for harsh environments, the Jinko 22kW Solar Pumping Inverter delivers reliable, energy-efficient, and cost-effective solar water pumping without the need for battery storage.

Product Features

Advanced MPPT Solar Optimization

Equipped with high-precision Maximum Power Point Tracking technology, the inverter continuously adjusts to extract the highest possible power from the solar array, improving efficiency and maximizing daily water output.

High Power Output for Large Pumps

With a 22kW rated capacity, this inverter is suitable for heavy-duty three-phase pumps used in large agricultural fields, commercial irrigation systems, and deep borehole installations.

Direct Solar Operation Without Batteries

Designed to run directly from solar panels, eliminating battery requirements and reducing overall system cost, maintenance, and energy losses.

Variable Frequency Drive Control

Integrated VFD functionality ensures smooth motor startup, adjustable speed control, reduced mechanical wear, and improved pump lifespan.

Comprehensive Protection System

Features built-in protection against overvoltage, undervoltage, overload, overcurrent, phase loss, overheating, dry-run conditions, and short circuits to safeguard both the inverter and connected pump.

Hybrid Backup Integration

Supports optional grid or generator input for hybrid operation, ensuring uninterrupted water supply during periods of low solar irradiance.

Durable Industrial Design

Constructed with high-quality components and efficient heat dissipation for stable performance in high-temperature and demanding outdoor environments.

Product Specifications

• Rated Power: 22kW
• Input Type: DC from solar photovoltaic panels
• Recommended PV Array Power: Up to 30kW depending on system design
• MPPT Efficiency: Up to 99%
• Output Type: Three-phase AC
• Output Voltage: 380V–415V AC
• Output Frequency: 0–50/60Hz adjustable
• Control Technology: Variable frequency drive with MPPT
• Compatible Pump Type: Three-phase AC water pumps
• Protection Features: Overvoltage, undervoltage, overload, overcurrent, overheating, dry-run, phase loss, short circuit
• Cooling Method: Intelligent forced air cooling
• Installation Type: Wall-mounted
• Operating Temperature Range: -10°C to +50°C
• Application Areas: Large-scale irrigation, borehole pumping, livestock watering, commercial agriculture, remote and off-grid water supply systems

Jinko 22kW Solar Pumping Inverter is an ideal solution for high-demand solar water pumping applications, offering dependable performance, reduced operational costs, and sustainable energy utilization for agricultural and commercial operations.
