Huawei SUN2000L-10KTL-M1 10kW Hybrid Solar Inverter – Three Phase Smart PV Inverter with Dual MPPT

Huawei SUN2000L-10KTL-M1 10kW Hybrid Solar Inverter is a high-performance three-phase grid-tied inverter designed for residential and small commercial solar power systems. Built with advanced digital control technology and dual MPPT tracking, this inverter maximizes solar energy harvest while ensuring stable and efficient power conversion. It supports battery integration for energy storage, enabling greater self-consumption and backup capability. With intelligent monitoring, high safety standards, and compact wall-mounted design, the Huawei SUN2000L-10KTL-M1 delivers reliable, efficient, and future-ready solar energy management.

Product Features

Dual MPPT for Maximum Energy Yield

Equipped with two independent Maximum Power Point Trackers, the inverter optimizes power output from multiple solar panel strings, increasing overall system efficiency even under partial shading conditions.

Hybrid Battery Compatibility

Supports integration with compatible high-voltage lithium batteries, allowing energy storage for increased self-consumption and backup power functionality during grid outages when configured with appropriate backup solutions.

High Conversion Efficiency

Delivers high DC to AC conversion efficiency, reducing energy losses and maximizing return on investment for residential and commercial solar installations.

Advanced Safety Protection

Includes comprehensive safety features such as DC arc fault protection, anti-islanding protection, overvoltage protection, short circuit protection, and real-time insulation monitoring for enhanced system reliability.

Smart Monitoring and Connectivity

Supports WiFi, Ethernet, and optional 4G communication for remote monitoring via Huawei’s smart energy management platform, enabling real-time performance tracking and system diagnostics.

Compact and Lightweight Design

Features a sleek, compact wall-mounted design that simplifies installation and saves space, making it ideal for residential rooftops and small commercial setups.

Silent and Natural Cooling

Designed with natural convection cooling and no external fans, ensuring low noise operation and improved long-term reliability.

Product Specifications

• Model: SUN2000L-10KTL-M1
• Rated AC Output Power: 10kW
• Phase Type: Three-phase
• MPPT Trackers: 2
• Maximum DC Input Voltage: Up to 1100V
• MPPT Voltage Range: Approximately 200V–1000V
• Maximum Efficiency: Up to 98.6%
• Battery Compatibility: High-voltage lithium battery support
• Communication Interfaces: WiFi, Ethernet, optional 4G
• Protection Features: DC arc fault protection, anti-islanding, overvoltage, overcurrent, short circuit, insulation monitoring
• Cooling Method: Natural convection
• Installation Type: Wall-mounted
• Ingress Protection Rating: IP65
• Operating Temperature Range: -25°C to +60°C
• Application: Residential and small commercial solar power systems

Huawei SUN2000L-10KTL-M1 10kW Hybrid Solar Inverter is an intelligent and efficient solution for modern solar energy systems, offering advanced monitoring, battery readiness, and high-performance energy conversion for reliable and sustainable power generation.
