D-Link DGS-1024D 24-Port Unmanaged Gigabit Switch
The D-Link DGS-1024D is a 24-port unmanaged Gigabit Ethernet switch designed to provide high-speed network connectivity for small to medium-sized businesses. Below are its detailed specifications:
Hardware Features:
- Ports: 24 x 10/100/1000 Mbps Gigabit Ethernet ports
- Auto MDI/MDIX: Eliminates the need for crossover cables
- Switching Capacity: 48 Gbps
- MAC Address Table: 8,000 entries
- Packet Buffer Memory: 512 KB
- Jumbo Frame Support: Up to 9,600 bytes
- LED Indicators: Per port: Link/Activity; Per device: Power
Performance:
- Forwarding Rate: 35.7 Mpps (million packets per second)
- Transmission Method: Store-and-forward
- Flow Control: IEEE 802.3x compliant
Design and Build:
- Housing: Durable metal case
- Fanless Design: Ensures silent operation
- Form Factor: Desktop or rackmountable
- Dimensions: 280 x 180 x 44 mm (11.02 x 7.08 x 1.73 inches)
- Weight: 1.3 kg
Power and Energy Efficiency:
- Power Input: 100 to 240 V AC, 50/60 Hz
- Maximum Power Consumption: 19.1 W
- Energy-Efficient Ethernet (EEE): IEEE 802.3az compliant
- D-Link Green Technology: Automatically powers down ports without a link and adjusts power based on cable length
Environmental Specifications:
- Operating Temperature: 0 to 40 °C (32 to 104 °F)
- Storage Temperature: -10 to 70 °C (14 to 158 °F)
- Operating Humidity: 0% to 95% non-condensing
- Operating Altitude: Up to 2,000 meters
Certifications and Compliance:
- Emissions: FCC Class A, CE Class A, VCCI Class A
- Safety: CSA International
- Environmental: RoHS compliant
The DGS-1024D is ideal for businesses seeking a reliable, energy-efficient, and high-performance networking solution. Its plug-and-play setup, combined with a fanless design, ensures easy deployment and quiet operation in various environments.
